Deep Learning Developer Product Portfolio

Dual-mode split desktop-level design, flexible and easy application and development

SC5 Deep Learning Computing Accelerator Card and SC5-IO Desktop SOC Expansion Card Dock

For developers who first use SOPHON BM1684 third-generation Deep learning processor series of computing hardware products (including SM5 edge modules, SC5+ accelerator cards, edge computing boxes and deep learning server.), SOPHGO provides a complete developer portfolio series, including SC5 single-processor board card and supporting I/O expansion dock. The SC5 single-processor development board is equipped with a BM1684 processor, which can support 38 channels of HD video hardware decoding, 2 channels of high-definition video encoding and more than 16 channels of video analysis. It also has a RESET button, UART debugging interface, and an active cooling fan with a large air volume. The development board can be adapted to the standard PC development and testing environment. Its device drivers and development test environment are consistent with SC5 (X) series accelerator cards and support simultaneous upgrades.

Application Scenarios

Educational research: deep learning laboratory, teaching experiment platform and visual classroom; Test & development: processor function verification, desktop-level development environment.

Easy-to-use, Convenient and Efficient

SOPHON SDK one-stop toolkit provides a series of software tools including the underlying driver environment, compiler and inference deployment tool. The easy-to-use and convenient toolkit covers the model optimization, efficient runtime support and other capabilities required for neural network inference. It provides easy-to-use and efficient full-stack solutions for the development and deployment of deep learning applications. SOPHON SDK minimizes the development cycle and cost of algorithms and software. Users can quickly deploy deep learning algorithms on various deep learning hardware products of SOPHGO to facilitate intelligent applications.

Support mainstream programming framework

More

Performance Parameter

Deep learning developer portfolio

Intelligent Accelerator Card SC5H

Intelligent Accelerator Card SC5+

TPU core architecture

SOPHON

SOPHON

SOPHON

SOPHON

NPU core number

64

-

64

192

Data Processing

Support FP32/BF16/FP16/INT8

-

Support FP32/BF16/FP16/INT8

Support FP32/BF16/FP16/INT8

16-channel HD video intelligent analysis

-

16-channel HD video intelligent analysis

48-channel HD video intelligent analysis

Processor

ARM 8-core A53 @ 2.3GHz

-

ARM 8-core A53 @ 2.3GHz

3x ARM 8-core A53 @ 2.3GHz

VPU

Video decoding capability

H.264:1080P @960fps
H.265:1080P @960fps

-

H.264:1080P @960fps
H.265:1080P @960fps

H.264:1080P @2880fps
H.265:1080P @2880fps

Video decoding resolution

CIF / D1 / 720P / 1080P / 4K(3840×2160) / 8K(8192×4096)

-


CIF / D1 / 720P / 1080P / 4K(3840×2160) / 8K(8192×4096)

CIF / D1 / 720P / 1080P / 4K(3840×2160) / 8K(8192×4096)

Video encoding capability

H.264:1080P @50fps
H.265:1080P @50fps

-

H.264:1080P @50fps
H.265:1080P @50fps

H.264:1080P @150fps
H.265:1080P @150fps

Video encoding resolution

CIF / D1 / 720P / 1080P / 4K(3840×2160)

-

CIF / D1 / 720P / 1080P / 4K(3840×2160)

CIF / D1 / 720P / 1080P / 4K(3840×2160)

Video transcoding capability (1080P to CIF)

Max. 18 channels

-

Max. 18 channels

Max. 54 channels

JPU

JPEG image decoding capability

480 images / second @ 1080p

-

480 images / second @ 1080p

1440 images / second @ 1080p

Maximum resolution (pixels)

32768×32768

-

32768×32768

32768×32768

System interface

Data link

EP PCIE X8
RC PCIE X8

PCIE X2

PCIE X16

PCIE X8

Operating mode

EP+RC

SOC extension

EP

EP

Physical / power interface

PCIE X16

12VDC Jack

PCIE X16

PCIE X16

RAM

Standard configuration

12GB

-

12GB

36GB

Maximum capacity

16GB

-

16GB

48GB

Power consumption

30W MAX

No load: 6W
With load: 30W

30W MAX

75W MAX

Heat dissipation mode

active

-

active

passive

Working status display

N/A

LED x3 (power / hard disk / status)

LED x1

LED x1

External I/O expansion *

SD-Card

1

-

-

RESET Button

1

-

-

RJ45

2 *1000Base-T

-

-

USB

4

-

-

SATA

1

-

-

4G/LTE

1

-

-

micro USB

1

-

-

working temperature

0℃-55℃

-10℃-55℃

0℃-55℃

Deep learning framework

Caffe / TensorFlow / Pytorch / Mxnet / Darknet / Paddle

Operating system support

Ubuntu / CentOS / Debian

compatibility

Compatible with mainstream x86 architecture and ARM architecture servers

Localization support

Support domestic processor systems such as Feiteng, Shenwei, Godson, Haiguang, etc. Support domestic Linux operating systems such as Kirin and UOS; Support domestic frameworks Paddle Lite, Tengine, etc.

Length x height x width (including bracket)

200x111.2x19.8mm

206x28.5x59.5mm

169.1x68.9x19mm

169.1x68.9x19.5mm

* All external I/O expansion interfaces in the deep learning developer portfolio must be used with SC5-IO
